Thermal Receipt Printer Custom VKP80 III
Product Description
VKP80III yog lub tshuab luam ntawv kiosk rau cov ntawv txais nyiaj thiab daim pib, cov neeg muag khoom sab saum toj thiab cov khoom siv hauv ntau tshaj 70 lub teb chaws hauv ntiaj teb. Compact, saj zawg zog thiab ruaj khov nws tseem muaj tag nrho ntawm cov yam ntxwv, xws li cov processor ua tau zoo thiab ntev -lub taub hau luam ntawv ntev. Nws yog haum rau txhua yam ntawm kiosk, ua tsaug rau lub adjustable yob tuav thiab muaj peev xwm mount nws ntawm ob sab, tag nrho 6 txawv txoj hauj lwm. VKP80III yog nruab nrog patented los tiv thaiv - jam system nrog jamming autodetection thiab nws pib eject retry, illuminated bezel thiab daim ntawv presenter nrog eject/retract function.
Khoom siv
Kev ua haujlwm
Tsis siv neeg daim pib ejecting & retractring rov qab (ceev> ntawm 1,000 mm/s)
Patented retracting muaj nuj nqi w/o daim pib nthuav qhia
Patented anti- jam system nrog jamming autodetection thiab nws pib eject rov ua dua
Kev sib koom ua ke muaj ntau yam nrog cov tsav tsheb thiab cov khoom siv rau Windows, Linux, Android thiab iOS
Hot swap muaj nuj nqi:nws muaj peev xwm hloov lub tshuab luam ntawv hauv kiosk w / tawm fais fab nws tawm
Sau lub taub hau tus kheej -diagnostic muaj nuj nqi: Nws tuaj yeem tau txais cov lej tsis ua haujlwm
Sensors
Daim ntawv kawg (daim daim pib), cov ntawv tso tawm, qhib lub tshuab luam ntawv npog, nyob ze ntawm daim ntawv kawg ntawm daim ntawv yob sab nraud, luam ntawv lub taub hau kub;
VeriNotch: mobile notch / black mark sensor, tsis muaj thermal sab; yeem TopNotch
Txuas ntxiv rau daim ntawv nyob ze ntawm qhov kawg sensor, nws tuaj yeem siv tau thaum daim ntawv yob tuav tau nruab 90℃ntawm sab xis
Daim ntawv thov
Tus kheej -kev pabcuam kiosks
Banking machines thiab nyiaj ntsuab dispenser
Cov tshuab ua si
Chaw nres tsheb meters
Cov tshuab muag khoom
Queue tswj systems
Khoom Specification
| Kev luam ntawv | Thermal nrog lub taub hau ruaj |
| Tus naj npawb ntawm cov dots | 8 dots/mm |
| Kev daws teeb meem | 203 DPI / txhim kho kev luam ntawv zoo |
| Kev luam ntawv (mm / sec) | Kev kub ceev> 250 mm / sec |
| Cim cim | PC437, PC850, PC860, PC863, PC865, PC858 |
| Hom ntawv luam tawm | Ib txwm, qhov siab thiab dav ntawm 1x txog 8x, thim rov qab, hauv qab, italic, bold |
| Phau Ntawv Qhia | Ncaj, 90 degree, 180 degree, 270 degree |
| Daim ntawv dav | los ntawm 50 mus rau 82.5 mm |
| Daim ntawv hnyav | los ntawm 55 mus rau 110 g / m² |
| Roll Dimension | max 150mm (Txog 250mm nrog xaiv yeem yob tuav) |
| Emulation | CUSTOM/POS |
| Interfaces | RS 232 + USB |
| Data Buffer | 16 KB ntawv nyeem / 1MB duab |
| Flash Nco | 5 MB (ntawm uas 1MB muaj rau tus neeg siv) |
| Cov tsav tsheb | Windows® (32/64 ntsis) - tsuas yog thov WHQL thiab ntsiag to installation; |
| Cov cuab yeej Software | PrinterSet, CustomPowerTool, Status Monitor, Custom Windows API |
| Fais fab mov | 24 VDC ± 10% |
| Kev noj nruab nrab | 1A (12.5% dots qhib) |
| MTBF | 450,000 teev (electronic board) |
| Lub taub hau lub neej | 100Km / 100M pulses |
| MCBF | 1,000,000 txiav |
| Ua haujlwm kub | -20℃+ 70 degree |
| Qhov ntev | 143.5 (L) x 76.4 (H) x 116 (W) mm |
| Qhov hnyav | 0.8 Kg |
Kev xa khoom pob
Exhibition Show & Cov neeg tuaj saib
FAQ Paub meej
Q: Kuv puas tuaj yeem yuav cov khoom siv sensor cais lossis tsuas yog bundled nrog load hlwb?
Ob leeg. Ntau tus neeg muas zaub yuav hlws ris lub thawv, transmitters, los yog cov cim qhia cais raws li kev hloov lossis rau kev hloov kho qhov system. Peb kuj muab cov khoom siv bundled nrog load cells ntawm luv nqi.
Q: Cov khoom siv dab tsi rau kiosk txee?
A: Yog tias sab hauv tsev kiosk, ces siv 1.2-1.5 hli thickness txias yob steel; Yog tias sab nraum zoov tiv thaiv xeb, ces siv Galvanized ntawv lossis stainless hlau
Q: Dab tsi xim rau kiosk?
A: Customized xim raws li tus neeg xav tau; zoo li Pantone lossis RAL tus lej;
Q: Dab tsi backup fais fab mov?
A: Xaiv cov qauv sib txawv UPS lub zog los txhawb nqa raws li tag nrho lub zog ntawm cov khoom siv kho vajtse;
Q: Ntev npaum li cas rau lub sijhawm khoom xa tuaj?
A: Feem ntau siv 30-45 hnub rau kiosk qauv tsim thiab ntau lawm; Tsawg lub sij hawm thaum txiav txim ntau tom qab aprroving qauv txiav txim;
